LED Module The modules are connected by a rotation axis. Each module have a 70° rotating range, while two or more modules can be rotated by 40°. This remarkable solution engineered for different requirement in outdoor lighting applications.

High Power and High Lumen Flux

HiMast has 300W, 600W and 900W power alternatives. And lumen flux are 40,500lm, 78,000lm and 117,000lm. They are designed to replace 600W, 1000W and 2000W MH/HID respectively.

Windproof & 10KV Surge Protection

It is reliable and windproof when tested at 30m height. Further more, it is compatible with a SPD that reaches 10KV rating, which operates well in bad weather.

Plug-and-Play

The LED modules connect driver by quality waterproof cable connectors, which can be plugged in and out quickly and safely.

DALI Control

1-10V Dimming

Light Distribution Optional

15 different distribution optics available for a wide range of different design and use.

HiMast

Remarkable modular LED flood light for sports fields, stadiums etc.

HiMast comes with an internal waterproof rubber gasket. And its well-deigned heat sink is airflow which prevents water accumulation. In addition, each module is equipped with a vent which prevents moisture. By reaching an excellent IP66 rating and with IK08 protection, it is reliable for outdoor usage.

IP66 & IK08
